Standard size
Mesh size / opening rate
Surface type
Resin type
craftwork
1.Surface type
M：meniscus (concave) top
S： smooth top
G：gritted top
C：covered top
O：other
2.Resin type
O:orthophthalic unsaturated polyester
I：isothophthalic unsaturated polyester
B：bisphenol A unsaturated polyester
V：vinylester
E：epoxy
P：phenolic
3.craftwork
M：moulded
P：pultruded
Example 1: MVM/38x38x38-3660x1220 stands for 38x38mm mesh, 38mm thickness, moulded grating in vinylester resin, with concave surface, standard size 3660x1220mm
Example 1: PIG/I-6038-6100x915 stands for 60% opening, 38mm thickness, pultruded grating in isophthalic resin, with gritted surface, standard size 6100x915mm
Available colours
The bright colors of Mincom FRP materials are made from compatible pigments evenly mixed into the resin. Different from color by surface painting, the colours of FRP materials are integrated inside and outside. The bright colours provide with a comfortable visual effects.
